Portable 1500W 2000W Handheld Laser Welding Machine 15m Fiber For Metal Laser Soldering

Name: Portable 1500W 2000W Handheld Laser Welding Machine 15m Fiber For Metal Laser Soldering
Brand: Zhongchi
Price: 1 USD

Quality Portable 1500W 2000W Handheld Laser Welding Machine 15m Fiber For Metal Laser Soldering for sale

Brand Name : Zhongchi

Model Number : LRL-HT

Certification : CE / ISO / FDA

Place of Origin : Shenzhen,China

MOQ : 1 UNIT

Price : Negotiable

Payment Terms : L/C, T/T, D/A, D/P, MoneyGram，PayPal

Supply Ability : 9000 Units per Month

Delivery Time : 10-15 days after payment

Packaging Details : Wooden Case Packing

Condition : New

Product name : Handheld Laser Welding Machine

Warranty : One year

Center Wavelength : 1080±5nm

Usage : Fiber laser welding

Optimal Operating Environment : Temperature 10-35 ° C, humidity 20% -80%

Applicable Industries : Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising C

Contact Now

Handheld Laser Welding Machine Portable Handheld Laser Welding Machine For Metal Laser Soldering 1500W 2000W 3000W

Product Description

Zhongchi Handheld Fiber Laser Welding Machine is a new type high-power, high-end continuous welding tool which adopts a high-quality fiber laser source to produce a fiber optic beam. After transmission processing, the light is focused on the workpiece to achieve continuous welding. It avoids the two thresholds of thermal strain and post-treatment, and is environmentally friendly and pollution-free, greatly improving the joint strength and quality of welding. Replacing the previously fixed light path with a hand-held type not only facilitates the welding of molds, advertising characters, kitchen utensils, doors and windows, etc., but also makes laser welding possible in outdoor operations, which indicates that the traditional welding of electric welding, argon arc welding, etc. will be replaced by laser welding.

Portable 1500W 2000W Handheld Laser Welding Machine 15m Fiber For Metal Laser Soldering

Features

Equipment characteristics (compare the advantages of argon arc welding and electric welding)
1. Simple operation, no need for professional personnel (low staff cost)
2. No welding scar, no deformation, weld level, reduce the later polishing process, save time and cost
3. Fast welding speed, 2-10 times faster than traditional welding, one machine can save at least 2 welders a year.
Portable 1500W 2000W Handheld Laser Welding Machine 15m Fiber For Metal Laser Soldering

Specifications

Laser Model	LRL-HT1500W	LRL-HT2000W	LRL-3000W
Power	1500W	2000W	3000W
Weld Requirements	<0.5mm
Fiber Length	10/15m (Optional)
Speed	0-120mm/s
Laser Wavelength	1080nm±5nm
Working Environment Humidity	<70%
Material Protection Gas	Aluminum Plate(N2)-Stainless Steel(Ar/N2)-Carbon Steel(Co2-N2-Ar)-Galvanized Sheet(Ar)
Weld Thickness of different materials	Stainless Steel 0.5mm Carbon Steel 0.5mm Galvanized Sheet 0.5-0.8mm	Aluminum Plate 1.0-1.5mm Stainless Steel 0.5-2.0mm Carbon Steel 0.5-2.0mm Galvanized Sheet 0.5-1.5mm	Aluminum Plate 1.0-2.0mm Stainless Steel 0.5-2.5mm Carbon Steel 0.5-2.5mm Galvanized Sheet 0.5-2.0mm

Applications
Portable 1500W 2000W Handheld Laser Welding Machine 15m Fiber For Metal Laser Soldering

FAQ

1. Q: Are you a manufacturer or a trading company?
A: We are a manufacturer established in 2017 ,now in Shenzhen China. Committed to providing the
majority of users with economic, high-quality laser equipment. Welcome to our factory.

2. Q: How long does it take to learn the laser?
A: The software is easy to learn with teaching video, also we can help you to learn the laser online. Usually it will take a few hours to operate the laser ,But it will take a bit of trial and error to learn what speed and power settings to use with different materials. So we include a comprehensive guide with your system that has recommended speed and power settings for various materials with which you will be working.

3. Q: Will the laser machine be safe during transport?
A: (1) Inner: plastic stretch film and white foam.
(2)Middle: small pieces of wood and screws.
(3)outside: standard export wooden case. So,the laser machine will send to you safely. In case the machine was damaged , please contact us ,We will process the replacement as soon as possible to ensure that it arrives in time .
